This product has been replaced by AM-14U4_PN8

AM14U3 Upgrade Kit for 6WD 8 in. Pneumatic Wheels, no wheels or belts - am-14U3-PN8_nobelt - migrated

AM14U3 Upgrade Kit for 6WD 8 in. Pneumatic Wheels, no wheels or belts

by AndyMark

$119.00 - $119.00

$119.00

$119.00

$119.00 - $119.00

$119.00

The information provided on this page is retained for posterity.

This product is no longer for sale at AndyMark and has been replaced by AM-14U4_PN8

Description
Specifications
Documentation

Note:
Please notice that this kit has NO WHEELS, BELTS, TIRES, TUBES or HUBS, and is NOT recommended for use with the AM14U4 2019 version of the Chassis. For AM14U4 we recommend this version of the kit: AM-14U4_PN8
The intention of providing this kit is for customers who already have the AM14U3 drive chassis and 8 in. Pneumatic Wheels. This kit includes the hardware, timing pulleys, spacers and fasteners needed for the conversion from a regular AM14U3 to one with 8 in. Pneumatic Wheels. But, this kit does not include the wheels or timing belts. This kit uses belts from the AM14U3 Chassis box.

This product is sold as a KIT and does not include the AM14U3 Chassis, the 8 in. Pneumatic Wheels or timing belts, only the components needed to change the wheels and properly space the outside plates from the inside plates are included.

Parts included:
- Two - Long Hex Output shaft, 4140 steel Toughbox (am-0801)
- Two - 370x375 Spacer (am-0440)
- Four - 3/8-16 x 5.15 in. Hex Bolt (am-1399)
- Two - 42 Tooth Pulley Extension (am-2813)
- Twelve - 10-32 Nylock Jam Nut, [Qty-50] (am-1211)
- Twelve - 10-32 x 3.50 in. SHCS (am-1402)
- Twenty Four - 10-32 Nylock Nut, Steel, Zinc Plated, [Qty-50] (am-1212)
- Twenty Four - 10-32 x 2.75 in. SHCS (am-1397)
- Eight - 250 Sprocket and Pulley Spacer (am-0207a)
- Four - 2x6 Bracket for AM14U3 (am-3299)
- One - 500 Churro Tube 19.25 in. +/- 0.125 in. (am-2241)
- Six - 0.850 in. long, 0.75 od, 0.380 id, Spacer (am-1307)
- Eight - Spacer, 0.145 in. long, 0.593 in. id, 0.875 in. od, Nylon (am-1151)
