This product has been replaced by am-3013b
40 Tooth 20 DP 0.5 in. Round Bore Aluminum Bolt Circle Bearing Gear for Swerve & Steer - am-3013a_1 - Image-1 - migrated

40 Tooth 20 DP 0.5 in. Round Bore Aluminum Bolt Circle Bearing Gear for Swerve & Steer

by AndyMark
$28.00 - $28.00
$28.00
$28.00
$28.00 - $28.00
$28.00

The information provided on this page is retained for posterity.

This product is no longer for sale at AndyMark and has been replaced by am-3013b

This product is currently unavailable for purchase

SKU am-3013a
  • Description
  • Specifications

  • This gear is a crucial part of the AndyMark Serve & Steer, swerve module. This component translate steering to the drive module from the steering motor.

    • Bore: 0.500 in. [12.7 mm] (1/2) Round
    • Diametral Pitch: 20
    • Face Width: 0.4 in.
    • Hole Pattern: Qty. 8 0.2 in. Holes on a 0.94 in. circle
    • Hub Depth: 0.65 in.
    • Hub Diameter: 1.249 in.
    • Material: 6061-T6 Aluminum
    • Overall Depth: 1.13 in.
    • Pitch Diameter: 2.1 in.
    • Pressure Angle: 14.5°
    • Teeth: 40
    • Weight: 0.108 lbs.
