KitBot 2025 REEFSCAPE℠

This kit is equivalent to the FRC Kit of Parts KitBot. In conjunction with an AM14U6 drive train, and one additional motor controller, these items can create a robot that can play some aspects of REEFSCAPE℠. It’s also been designed so teams can build the KitBot and then further iterate on it to add additional features if they choose. Teams will still need basic power tools (drills, saws, etc.) in order to build this robot.

Options include either pre-drilled box tubing or plain box tubing for the creation of the robot structure.

Note: Our kit uses a modified plate design to accommodate off the shelf pulleys with a 24 to 42 tooth belt spacing.

Resources that will be made available by FIRST include:

• Build instructions for the KitBot with photos
• Basic code to operate the KitBot as designed in LabVIEW, Java, C++, and Python
  • Software guide for each language exploring the code and possible controls modifications
• CAD drawings of the KitBot
• A guide to describe the process of adding or improving the functionality of the KitBot
• Assembly Videos

Included Items:

• 1 - 8mm Push On Retaining Ring (am-0033)
• 1 - 2.5 in. CIM Motor (am-0255)
• 6 - 10-32 x 1 in. Socket Head Cap Screw (am-1056)
• 72 - 10-32 Nylock Jam Nut (am-1063)
• 2 - Screw, SHCS 10-32 x 5/8 in. w/ Nylon Thread Lock Patch (am-1120)
• 1 - 2mm x 10mm Machine Key Steel (am-1121)
• 2 - 0.5 in. Hex HD Collar Clamp Silver (am-1526)
• 10 - Cable Tie, 8 in., 50lb tensile, Black (am-1552_black)
• 66 - Screw, BHCS, 10-32 x 1.5 in. (am-1730)
• 2 - Pulley, Half, 42 Tooth, HTD, 15mm Wide, Blind Pockets, Black Polycarbonate (am-2234a_half)
• 1 - 500EX Hex Hub (am-2568)
• 1 - Gaffers Tape 2 in. x 18' (Random color) (am-294X-18)
• 2 - 1/2 in. Hex Shielded Flanged Bearing (FR8ZZ-HexHD) (am-2986)
• 2 - Pulley Half, 24T HTD 0.5 in. Hex Bore (am-3403_half)
• 1 - 24 Tooth HTD Pulley Extension (am-3404)
• 5 - 4 in. Compliant Wheel 1/2 in. Hex Bore 35A Durometer (am-3480_green)
• 1 - 0.500 in. Hex Molder Spacer 0.100 in. Long (am-3948-100)
• 12 - 0.500 in. Hex Molded Spacer 1.000 in. Long (am-3948-1000)
• 1 - 0.500 in. Hex Molded Spacer 0.125 in. Long (am-3948-125)
• 1 - 0.500 in. Hex Molded Spacer 0.250 in. Long (am-3948-250)
• 1 - 0.500 in. Hex Molded Spacer 0.500 in. Long (am-3948-500)
• 4 - 1 in. Tee Gusset (am-4158)
• 6 - Square Tubing, 3', 1 in. x 1 in. with 0.063 in. Wall - 6061 (am-4203-3)
• 1 - Belt, Timing, HTD, 5mm Pitch, 15mm Wide, 130T, 650-5M-15 (am-5215_130T)
• 1 - Gusset, KitBot 2025 70 degree (am-5596)
• 1 - Gusset, KitBot 2025 Roller (am-5597)
• 1 - 8mm to 1/2 in. Hex Shaft Adapter (am-0588_long)
• 3 - 0.5 in. 7075 Aluminum Hex Shaft Stock (am-2291-3)
• 5 - 2 in. Wide Velcro Hook Adhesive Back (am-3569a_05)
• 3 - 24 in. x 24 in., 0.118 in. Thick Polycarbonate Sheet (am-0980)
• 1 - 32 in. x 18 in., 0.118 in. Thick Polycarbonate Sheet (am-5598)

• 1 - 8mm Push On Retaining Ring (am-0033)
• 1 - 2.5 in. CIM Motor (am-0255)
• 6 - 10-32 x 1 in. Socket Head Cap Screw (am-1056)
• 72 - 10-32 Nylock Jam Nut (am-1063)
• 2 - Screw, SHCS 10-32 x 5/8 in. w/ Nylon Thread Lock Patch (am-1120)
• 1 - 2mm x 10mm Machine Key Steel (am-1121)
• 2 - 0.5 in. Hex HD Collar Clamp Silver (am-1526)
• 10 - Cable Tie, 8 in., 50lb tensile, Black (am-1552_black)
• 66 - Screw, BHCS, 10-32 x 1.5 in. (am-1730)
• 2 - Pulley, Half, 42 Tooth, HTD, 15mm Wide, Blind Pockets, Black Polycarbonate (am-2234a_half)
• 1 - 500EX Hex Hub (am-2568)
• 1 - Gaffers Tape 2 in. x 18' (Random color) (am-294X-18)
• 2 - 1/2 in. Hex Shielded Flanged Bearing (FR8ZZ-HexHD) (am-2986)
• 2 - Pulley Half, 24T HTD 0.5 in. Hex Bore (am-3403_half)
• 1 - 24 Tooth HTD Pulley Extension (am-3404)
• 5 - 4 in. Compliant Wheel 1/2 in. Hex Bore 35A Durometer (am-3480_green)
• 1 - 0.500 in. Hex Molder Spacer 0.100 in. Long (am-3948-100)
• 12 - 0.500 in. Hex Molded Spacer 1.000 in. Long (am-3948-1000)
• 1 - 0.500 in. Hex Molded Spacer 0.125 in. Long (am-3948-125)
• 1 - 0.500 in. Hex Molded Spacer 0.250 in. Long (am-3948-250)
• 1 - 0.500 in. Hex Molded Spacer 0.500 in. Long (am-3948-500)
• 4 - 1 in. Tee Gusset (am-4158)
• 5 - 47 in. long, 1 in. x 1 in. x 0.063 in. Wall Pre-Drilled Square Tube (am-5177)
• 1 - Belt, Timing, HTD, 5mm Pitch, 15mm Wide, 130T, 650-5M-15 (am-5215_130T)
• 1 - Gusset, KitBot 2025 70 degree (am-5596)
• 1 - Gusset, KitBot 2025 Roller (am-5597)
• 1 - 8mm to 1/2 in. Hex Shaft Adapter (am-0588_long)
• 3 - 0.5 in. 7075 Aluminum Hex Shaft Stock (am-2291-3)
• 5 - 2 in. Wide Velcro Hook Adhesive Back (am-3569a_05)
• 3 - 24 in. x 24 in., 0.118 in. Thick Polycarbonate Sheet (am-0980)
• 1 - 32 in. x 18 in., 0.118 in. Thick Polycarbonate Sheet (am-5598)
