Nason Pressure Switch

by AndyMark
$48.00 - $48.00
$48.00
$48.00
$48.00 - $48.00
$48.00
This is an air pressure switch with a factory preset setting of 115-120 psi.
SKU am-2006
  • Description
  • Specifications
  • Documentation
  • This switch is able to send a signal to a robot controller, which can then tell a pneumatic compressor (air pump) to stop operating.
    • Circuit: SPST-NC
    • Current Rating: 5 A @ 30 VDC
    • Cycle Life: 1 million
    • Fixed set point: 115 psi
    • Manufacturer: Nason
    • Manufacturer Part #: SM-2B-115R/443
    • Maximum Operating Pressure: 250 psi
    • NEMA Rating: NEMA 4, 13
    • Port(s): 1/8 in. NPT Male
    • Screw Terminals: #8-32
    • Set Point Direction: Rising

  • Datasheets

    am-2006 Data Sheet.pdf
